1CH 433MHZ 12VDC Wireless Remote Control Switch Transmitter & Receiver

start of prefixes

• 1-Channel Wireless remote control
• Simply Operate, Study key for set up
• The programmable transmitter and receivers can be flexibly configured in quantity and in operating modes
• Working mode: Momentary, Toggle, Momentary with 3 seconds time delay
• It is widely used in industrial control and security fields, such as light, motor, remote controller, wireless security alarm, wireless door alarm, wireless controller, etc.

Key Features:

• 12V DC input.

• Work model: Jog-lock (comment) / self-lock / interlock.

• Timer function: 10s/30s/90s/120s.

• PCBA Size: 30*35*18mm

• Cover size: 55*37*25mm/55*37*25mm

• It can be paired with 35 remote controllers at the same time

How to set the working mode:

• How to clear the code - Press the paired button on the board 8 times, light flash, clear code successfully.

• How to set remote working mode - Turn on the switch, then Jog-lock (remark) Press the "pairing" button once, the red light on, then press the remote control button, the red LED flashes, then off, the race mode completed.

• Self-locking - Press the paired button twice quickly, the red light turns on, then press the remote control button, the red LED flashes, then turns off, the self-locking mode is completed.

• Interlock - (you need a remote control with 2 buttons).
