9CH CCTV Power Supply Box DC 12V 10A

start of prefixes

• 9 channel DC 12V 10A CCTV Cameras Power Box Switching Power Suply BOX for CCTV Video Camera 9CHs Port Input AC 100-240V to DC 12V

Techinical Specifications:

• OUTPUT DC Port:9 Channel
• OUTPUT VOLTAGE:DC 12V
• RATED CURRENT:DC 10A
• RATED POWER:120W
• Support to:9PCS Cameras
• INPUT VOLTAGE RANGE:AC 100-120V, AC 200-240V, 50Hz / 60Hz
• FREQUENCY RANGE:47-63HZ
• LEAKAGE CURRENT:1mA/240VAC
• ENVIRONMENT:WORKING TEMP -10~+60°C
• WORKING HUMIDITY:20-90%RH non-condensing
• STORAGE TEMP,HUMIDITY:-20~+85°C,10-95%RH
• Shell Material:Metal case / Aluminum case
• DIMENSION:235X205X54 mm
