AccessPro Door Lock Magnetic 350 Lbs/ Plate Lock Sensor

start of prefixes

• 350lbs Magnetic Lock: Use magnetic power to lock the door, 350lbs/180kgs holding force. Design non-slip and durable.
• NC mode Unlocked when power off, locked when power on, fail safe mode, Built-in voltage spike suppressor.
• Metal Lock body, Alluminum shell adopts high strength material, with hard anodised processing, corrosion resistant, good quality.
• Working with: 12V/300MA; 14 to 131 Fahrenheit, DC 12V, can be opened by push button, remote control, etc. (Not included)
• Suitable for Hanging and embedded types install, fit for wooden door, metal door, glass door, fireproof door, etc.

Specifications:

• Clamping force - 180 kg (350 lbs).

• Voltage - 12/24 Vdc.

• Power consumption - 12V / 300mA, 24V / 150mA.

• State plate lock sensor.

• Magnet finish - Anodized aluminum.

• Magnet dimensions - 7.20 x 1.62 x 0.80" (183 x 41.4 x 20.5 mm)

• Board dimensions - 5.11 x 1.29 x 0.36" (130 x 33 x 9.3 mm).

• Weight - 2.64 lb (1.2 kg).

• 1 Year Warranty.
