Altronix 12VDC Or 24VDC @ 6A Power Supply / Charger

SMP7CTX power supply/charger converts a 115VAC / 60Hz input into a regulated 12VDC or 24VDC output @ 6A continuous supply current.

• Input

  • Input 115VAC, 60Hz, 2.5A.

• Output

  • 12VDC or 24VDC selectable output.
  • 6A supply current.
  • Filtered and electronically regulated outputs.
  • Short circuit and thermal overload protection.

• Battery Backup

  • Built-in charger for sealed lead acid or gel type batteries.
  • Zero voltage drop when switching over to battery backup.

• Visual Indicators

  • AC input and DC output LED indicators.

• Temperature

  • Operating: 0° C to 49° C (32° F to 120° F).
  • Storage: - 20° C to 70° C ( - 4° F to 158° F).
  • Relative Humidity 85% +/- 5%.

    • BTU/Hr (approx.):

      • 12VDC: 37 BTU/Hr.
      • 24VDC: 74 BTU/Hr.
  • System AC input VA requirement: 287.5VA.
