The Logic Controls LE1015 true flat, bezel-free touch monitor is designed and manufactured to meet the requirements of retail or restaurant operations as part of a Point of Sale system. The LE1015 touch monitor also facilitates quick and professional mounting of integrated magnetic stripe reader and VFD/LCD customer display, The highly rugged touch monitor includes a solid base with an extra wide hinge for maximum stability
Main Features:
- A true flat, bezel-free design
- Projected Capacitive Touch (PCAP).
- Durable and sturdy base
- Supports integrated MSR and 2nd display
- Proven reliable performance
- Built-in universal power supply
- Built-in speakers
- USB touch interface
LCD TOUCH PANEL
LCD size: 15in (38.1cm)
Display active area: 11.9in x 8.9in (30.4cm x 22.8cm)
Brightness: 250 cd/m2
Response time: 12ms
Contrast ratio: 800:1
Resolution: XGA 1024 x 768 @ 75Hz, 16.2M colors
Viewing angle: (CR>10) Horizontal: 90°, Vertical: 60°
Touch screen: Projected Capacitive Touch (PCAP).
ELECTRICAL
Power supply: Built-in universal power
Input: 100~240VAC, 50/60Hz
Power consumption: 30W max
Power saving mode: 1W max
Power off mode: 0.5W max
ENVIRONMENTAL
Operating temperature: 41°F to 104°F (5°C to 40°C)
Relative humidity: 20% – 80%, non-condensing
MISCELLANEOUS
Plug & Play: DDC2B
VESA wall mount compatible: 3.94in x 3.94in (10.0cm x 10.0cm)
Power management: VESA DPMS
Magnetic stripe reader (optional): Track 1/2/3, USB interface
Customer display (optional): 8in LCD or 2×20 VFD, USB interface
