Bematech LR110E Ethernet Reciept Printer

start of prefixes

About this item:

ETHERNET INTERFACE -  NOT USB

• A Cost Effective Thermal Printer – The LR1100 is a fast high quality POS printer using thermal technology for printing.
• It optimizes the checkout process and helps accelerate business at the Point of Sale.
• Ethernet is ideal for network printing applications.
• The wide range of software tools assist in quick and easy setup of the LR1100 printers in the application environment.

Main Features:

• Fast printing up to 9.8″ per second
• Ethernet interface
• Easy and quick installation and setup
• Low noise printing
• ESC/POS command set emulation

Specifications

PRINTING
Printing Method Direct thermal printing
Resolution 203dpi (8 dots/mm)
Paper Width 79.5 ± 0.5mm
Printing Width 72mm
Character Font ASCII Font A: 12×24 ASCII Font B: 9×17
Printer Density 576 dots/line
Printing Speed 250 mm/s

PAPER
Paper Type Thermal paper
Paper Width 80mm
Paper roll diameter Max 80mm

SENSOR
Paper sensor Paper end, Paper low

LIFE SPAN
Printer Head service lifetime 15,000,000 lines (100Km)
Auto-cutter 1,000,000 cuts
MCBF 60,000,000 lines

ELECTRICAL
Power adapter input AC 100-240V, 50/60Hz
Power adapter output DC 24V, 2.5A

COMMUNICATION INTERFACES
LR1100E Ethernet

CONNECTORS
Ethernet (LR1100E) RJ45
Cash Drawer RJ11
Power 3-pin with latch

CASH DRAWER PORT
Solenoid drive signal DC24V, 1A
Number of drawers 2 (split cable required)
Drawer status sensor Supported

MECHANICAL
Weight 2.6 lbs (1.2Kg)
Dimension (WxDxH) 5.5″ x 7.8″ x 5.1″
(140mm x 198mm x 130mm)
