PoE Powered and 100M Extension Distance
The PoE extender is powered by PoE Switch that comply with IEEE 802.3af/at Standards. It extends a single PoE/PoE+ network connection up to an additional 100m (328 ft.) for a remote PoE or PoE+ device.
Support 3 Level Cascading
Each 4 port PoE extender can extend an additional 100m distance, and support up to 3 PoE extenders connected at the same time, extending the distance over 1300 feet.
Gigabit Transmission Speed
This PoE extender supports gigabit speed, higher speed to meet the more needs of users. It is a good assistant for surveillance system.
Waterproof Casing Design
The 3 sides of the shell are made of one-piece injection molding process,with vertical installation on the wall, which can be use in outdoor.
Plug and Play
This PoE repeater does not need any set up, plug & play, easy to use. All ports support automatic device detection to protect the device from damage.
4KV Lightning Protection
4KV Lightning Protection for complex outdoor weather conditions ;
Working temperature: -10°c to 55°c;
Working Humidity: 10%~90%, No Condensation;
4 Port Gigabit PoE Extender
The 4 port outdoor PoE extender features 1 PoE in and 3 PoE out.Working with PoE switch and no power required.Each PoE extender has an transmission distance of 330ft(100m), running one cable to power 3 POE IP devices.
IEEE 802.3 af/at
This POE Repeater complied with standard PoE Protocol, Input Max 30W, Output Max 24W, Average 8W per port. PoE Voltage 44-57 Vdc. PoE pin: Input, 1/2 (-), 3/6 (+), 4/5(+), 7/8(-); Output: 1/2 (+), 3/6 (-).
Plug and Play
Plug and play,the PoE Extender is easy to setup with no software installation or configuration required.(This product must be used with a PoE switch)
Widely Application
The 4 port PoE repeater Support 3-level cascading, can connect poe AP, camera, phone and other POE devices, increase POE coverage at low cost
One-Key VLAN
Supports Port-Based VLAN:1-4 port is isolated with each otherbut communicate with upLink ports to improve network performance
For surveillance
This PoE extender supports gigabit speed, higher speed to meet the more needs of users. It is a good assistant for surveillance system. Moreover,we provide product- replace- without- repair service within 2 years, more concern on your using experience.
