Dahua 128CH 4K Ultra H.265 Network Video Recorder

start of prefixes

• New 4.0 user interface
• 16-channel decoding @1080p (30 fps); self-adaptive decoding capability
• Access, storage or forwarding at 384 Mbps
• Simultaneous video output for VGA and HDMI1; 4K heterogeneous output for the 2 HDMI ports
• Multiple data mode such as Raid0, Raid1, Raid5, Raid6, and Raid10
• Remote configuration and management of IPCs, such as setting pa rameters, acquiring information and upgrading IPCs of the same model in batches
• AI-by-camera functions such as perimeter protection, face detection and recognition, SMD Plus, video metadata, ANPR and 3D behavior analysis
• N+M cluster. When the host fails, the standbydevice will continue to record; once the host recovers,video recorded on the standby device will be transmitted back
• Recording Mode: Real Time / Timelapse / Event
• Video inputs: 128
• Inbuilt multiplexer: Yes
• Max 128 channel IP cameras connection
• Max 384Mbps incoming bandwidth
• Up to 12Mp resolution preview& playback
• 1 VGA+2 HDMI
• Support 16 hot-swap HDDs
• Support RAID 0/1/5/6/10/50/60
• Support N+M hot standby
• Support iSCSI & Mini SAS to expand storage space
• Compatible with Dahua SDK and seamless integrated to other platforms
• Support Multi-brand network cameras: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek and etc.
• ONVIF Version 2.4 conformance
• Redundant power supply module adopted (DH-NVR616R-128 &DH-NVR616DR-128)
• Front LCD display (DH-NVR616D-128 & DH-NVR616DR-128)
