Hikvision 1080P/2MP Outdoor 2.8mm Bullet HD Analog Camera Switchable TVI/AHD/CVI/CVBS Up to 40M IR range

(No reviews yet) Write a Review
SKU:
DS-2CE17DOT-IT3F
UPC:
6941264039723
Add to Cart

Options

Online price $48.99
Or

Info

SKU:DS-2CE17DOT-IT3F ,UPC:

Info

SKU:
DS-2CE17DOT-IT3F
UPC:
6941264039723

Description

2 MP Fixed Bullet Camera

  • High quality imaging with 2 MP, 1920 × 1080 resolution
  • 2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed focal lens
  • Up to 40 m IR distance for bright night imaging
  • One port for four switchable signals (TVI/AHD/CVI/CVBS)
  • Water and dust resistant (IP67)



        Camera

  • Image Sensor2 MP CMOS
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
  • Shutter Time

    PAL: 1/25 s to 1/50,000 s

    NTSC: 1/30 s to 1/50,000 s

  • Day & NightICR
  • Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
  • Signal SystemPAL/NTSC


    Lens
  • Lens Type2.8 mm, 3.6 mm, 6 mm, 8 mm, 12 mm fixed lens
  • Focal Length & FOV

    2.8 mm, horizontal FOV: 106.4°, vertical FOV: 57.9°, diagonal FOV: 124.6°

    3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7°

    6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8°

    8 mm, horizontal FOV: 39.9°, vertical FOV: 21.9°, diagonal FOV: 46.5°

    12 mm, horizontal FOV: 24.6°, vertical FOV: 13.9°, diagonal FOV: 28.1°

  • Lens MountM12




  • Image Parameters SwitchSTD/HIGH-SAT
  • Image SettingsBrightness, Sharpness, Smart IR
  • Frame Rate

    TVI: 1080P@30fps, 1080P@25fps

    CVI: 1080P@30fps, 1080P@25fps

    AHD: 1080P@30fps, 1080P@25fps

    CVBS: PAL/NTSC

  • Day/Night ModeAuto/Color/BW (Black and White)
  • Wide Dynamic Range (WDR)Digital WDR
  • Image EnhancementDWDR/BLC/HLC/Global
  • Noise ReductionYes
  • White BalanceAuto/Manual
  • AGCYes


    Interface
  • Video OutputSwitchable TVI/AHD/CVI/CVBS


    General
  • Material

    Front Cover: Metal

    Main Body: Plastic

  • Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
  • CommunicationHIKVISION-C
  • LanguageEnglish
  • Power Supply12 VDC ± 25%
  • ConsumptionMax. 3.9 W
  • IR RangeUp to 40 m

    Approval
  • ProtectionIP67
