Hikvision 1080P Fixed Turret Outdoor Dome HD Analog Camera 2.8MM Switchable TVI/AHD/CVI/CVBS Up to 20m IR range

(No reviews yet) Write a Review
UPC:
6954273694470
MPN:
DS-2CE56DOT-IT1F
Custom text:
This item is eligible for free shipping See More.
Add to Cart

Options

Online price $42.00
Or

Info

,UPC:

Info

UPC:
6954273694470
MPN:
DS-2CE56DOT-IT1F
Custom text:
This item is eligible for free shipping See More.

Description

start of prefixes

2 MP Fixed Turret Camera

  • 2 MP turret camera
  • EXIR 2.0: advanced infrared technology with 20 m IR distance
  • Water and dust resistant (IP66)
  • 4 in 1 (4 signals switchable TVI/AHD/CVI/CVBS)
  • Camera
  • Image Sensor2 MP CMOS image sensor
  • Max. Resolution1920 (H) × 1080 (V)
  • Min. Illumination0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
  • Shutter Time1/25 (1/30) s to 1/50,000 s
  • Day & NightIR cut filter
  • Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
  • Signal SystemPAL/NTSC
  • Lens
  • Lens Type3.6 mm 2.8 mm, 6 mm fixed lens
  • Focal Length & FOV103° (2.8 mm), 82.2° (3.6 mm), 54° (6 mm)
  • Lens MountM12
  • Image
  • Image SettingsBrightness, Sharpness, DNR, Mirror
  • Frame RatePAL: 1080p@25fps,NTSC: 1080p@30fps
  • Day/Night ModeSmart/color/BW(Black and White)
  • Wide Dynamic Range (WDR)DWDR
  • Image EnhancementBLC
  • AGCLow/middle/high
  • Interface
  • Video OutputSwitchable TVI/AHD/CVI/CVBS
  • General
  • MaterialPlastic
  • DimensionΦ 110 mm × 93.2 mm (4.33" × 3.67")
  • WeightApprox. 350 g (0.77 lb.)
  • Operating Condition-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
  • LanguageEnglish, Chinese
  • Power Supply12 VDC±15%
  • ConsumptionMax. 4 W
  • IR RangeUp to 20 m
  • Approval
  • ProtectionIP66
