Features:
• Third-party network cameras supported
• Up to 8 Megapixels resolution recording
• Support 1-ch HDMI, 1-ch VGA, HMDI at up to 4K(3840x2160)
resolution
• 32-ch network cameras can be connected with
160M/256M incoming bandwidth
• Up to 4 SATA interfaces
• Support dual-os to ensure high reliablility of system
running
•Support various VCA detection alarm and VCA search
•Support H.265/H.264/MPEG4 video formats
| Video/Audio Input |
| Two-way audio input: | | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input: | | 32-ch |
| Network |
| Remote connection: | | 128 |
| Incoming bandwidth: | | 256Mbps |
| Outgoing bandwidth: | | 160Mbps |
| Video/Audio Output |
| HDMI Output: | | 1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Recording Resolution: | | 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output: | | 1-ch, RCA (Linear, 1kΩ) |
| Synchronous Playback: | | 16-ch |
| VGA Output: | | 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Decoding |
| Capability: | | 8-ch@1080P |
| Live view / Playback: | | 8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Hard Disk |
| SATA: | | 4 SATA interfaces for 4HDDs |
| Capacity: | | Up to 6TB capacity for each HDD |
| External Interface |
| Network Interface: | | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface: | | RS-232; RS-485; |
| USB Interface: | | Front panel: 2 × USB 2.0
Rear panel: 1 × USB 3.0 |
| Alarm In: | | 16-ch |
| Alarm Out: | | 4-ch |
| General |
| Power Supply: | | 100 to 240 VAC |
| Consumption(without hard disk and POE): | | ≤20 W |
| Working Temperature: | | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity: | | 10 % ~ 90 % |
| Chassis: | | 19-inch rack-mounted 1.5U chassis |
| Dimensions: | | 445 × 390 × 70 mm (17.5"× 15.3" × 2.8") |
| Weight(without HDD): | | ≤ 5 Kg (11 lb)
|
