See and speak to people at your door before letting them in from the DS-KH8350-WTE1 7" Indoor Video Intercom Station with 7"Color Touchscreen from Hikvision. You can do more than just communicate with visitors by integrating this station into your existing Hikvision surveillance or access control system. Integration enables users to view feeds from other cameras or door stations on the network, check system status, and remotely unlock an entryway.
This station can receive power over Ethernet to simplify installation when connecting it to your network via RJ45. Where running cable is inconvenient, it can also connect via Wi-Fi.
-
KH8 Series Indoor Station
- 7-inch IPS touch screen with 1024 × 600 resolution
- Reddot award winner
- Convenient Hik-Connect APP Mobile Control
- Receive calls, open the door and live view remotely
- Easy to use without PC
- Easy wizard for quick set up
- Configure the whole system on one touch screen
- Rich functions and extensions
- Live-view of the door station and cameras in public areas
- Support voice messages when no response from the indoor station
- Receive alarms by internal alarm terminals
- Elevator access control
- System Parameters
- Operation SystemLinux
- ROM32 MB
- RAM128 MB
- ProcessorEmbeded high performance processor
- Display Parameters
- Screen Size7-inch
- Operation MethodCapacitive touch screen
- TypeColorful IPS
- Resolution1024 × 600
- Video Parameters
- Lens/
- Resolution/
- FOV/
- Wide Dynamic Range (WDR)/
- Video Compression Standard/
- Focal Length/
- Audio Parameters
- Audio Input1 built-in omnidirectional microphone
- Audio Compression StandardG.711U/G.711A
- Audio Output1 built-in loudspeaker
- Audio InputBuilt-in omnidirectional microphone
- Audio Compression Bitrate64 Kbps
- Audio QualityNoise suppression and echo cancellation
- Volume AdjustmentAdjustable
- Capacity
- Notice Capacity200
- Linked Indoor Extensions Capacity16
- Linked Doorphone Capacity17
- Linked Network Camera Capacity16
- Network Parameters
- Network ProtocolTCP/IP, SIP, RTSP
- Wi-Fi2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n
- Bluetooth/
- 3G/4G/
- Zigbee/
- Device Interfaces
- Alarm Input8
- Network Interface1 RJ-45 10/100 Mbps self-adaptive
- TAMPER/
- RS-4851 RS-485 (Half duplex)
- USB/
- TF CardSupport TF card, up to 128 G
- Alarm Output2
- Lock Control2 high/low level relays (3.3V/0V)
- General
- Button1 physical button
- InstallationSurface mounting
- Indicator/
- Weight
- Protective Level/
- Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
- Working Humidity10% to 90% (no-condensing)
- Dimension (W × H × D)180 mm × 140 mm × 22.4 mm (7.09" × 5.51" × 0.88")
- Battery/
- Power Supply12 VDC, 1 A, IEEE802.3af, standard PoE
- Application EnvironmentIndoor
- Power Consumption≤ 8 W
- LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese (Brazil), Spanish, Hebrew, Romanian, Turkish, Estonian, Danish, Swedish, Norwegian, Finnish, Vietnamese, Croatian, Slovenian, Serbian, Arabic, Portuguese (Portugal), Lithuanian, Uzbek, Kazakh, Mongolian, Ukrainian
