Holland Electronics HCG 24 Passive Combiner

• The HCG-24 is a 24 input passive head-end combiner, intended to combine many modulator and processor outputs into one while maintaining the highest isolation between ports. The HCG-24 is used on systems requiring 1 GHz bandwidth.
• Directional Coupler Design
• Low Insertion Loss
• Front Panel Test Port
• High Port-to-Port Isolation

Specifications

• Frequency Range - HCG-24 51000 MHz

• Insertion Loss -16 dB (±1.5dB)

• Port-to-Port Isolation - 40 dB

• Return Loss - 18 dB

• Test Port -20 dB

• Dimensions - 19"W x 1.75"H 3"D
