Honeywell 16.5VAC, 40VA 2.4A Power Transformer

start of prefixes

• The Honeywell 1361-GT is a 3-prong, 16.5VAC, 40VA, 2.4A step-down power transformer designed to work with the Honeywell VISTA-Series control panels. The 1361-GT primary rated voltage and frequency is 120VAC, 60Hz.
• The 1361-GT has a plastic encased plug-in construction with mounting tab. The 1361-GT secondary nominal voltage is 16.5VAC at 2.42A (40VA) and at 120VAC, 60Hz.
• The 1361-GT has two male blades (AC, AC) and one round male ground pin (GND). The primary AC terminal GND to be shorted to secondary AC terminal GND with a minimum 18AWG wire 4.
• The secondary output terminals are AC, GND, AC. Three #6-32 UNC pan-head nickel plated brass (captured) screw terminals for 16-24 gauge wire.

Product Features:

• Rated power: 40VA
• voltage input: 16.5V ac
• Current: 2.40A
• Transformer, 16.5VAC, 40VA, 2.4A
• Weight: 1.1 lbs
