Linkedpro 48 Port Cat6 Patch Panel

start of prefixes

• ICC’s Category 6 (CAT6) 48-port, 2 rack mount spaces (RMS) patch panels surpass industry requirements for Category 6 performance.
• These horizontal patch panels are designed with a rear 110 IDC’s for quick and easy punch-down termination and come integrated with a universal label allowing for either 568-A/B wiring. Package includes mounting screws.

Key Features:

• Rack-mounted CAT 6 component rated patch panel provides excellent performance for data networks requiring maximum speed and bandwidth.
• Supports Power over Ethernet (PoE++) Type 4; up to 100 Watts on each port.
• Enhanced crosstalk cancellation reduces return loss (AXT).
• Exceeds ANSI/TIA-568-B.2 Category 6 connecting hardware requirements.
• Engineered to provide 110 IDC termination reducing installation time.
• Includes both TIA-568A and TIA-568B color wiring diagrams.
• Backwards compatible with all lower rated category components.
• Designed to fit all standard 19″ racks and cabinets.
• 2 rack mount spaces (RMS).
• Used with CAT6 patch cords, 110 punch down tool, and 4-pair 110 punch down tool.
