The HD-EX250SR HDMI extender is designed to convert HDMI signal to standard TCP/IP and transmit by CAT5e/6 or LAN Cable with the advantage of TCP/IP standard, it can transmit HDMI signal source from HD STb,DVD,PS3, HDMI display card etc to HD projector, DLP,LCD,LED and other audio visual equipments. Extends by Router connection or LAN connection ,Cable length requirements are as follows:
CAT5 Maximum 80 meters between two Device
CAR5e Maximum 100 meters between two Device
CAT6 Maximum 120 meters between two Device
Specification:
• Power Supply: 2x 5V DC/1A, Input: AC 100-240V, 50/60Hz, 0.3A
• Supports resolutions: 480i/60Hz, 480p/60Hz, 576i/50Hz, 560p/50Hz, 720p/50/60Hz, 1080i/50/60Hz, 1080p/50/60Hz
• Working Temperature: -10°C~60°C
• Link Connector(Sender/Receiver): UTP/STP CAT5e/6
• Power Consumption: 3W(max) each
• Relative Humidity: 20%~90%
• Dimensions: 4.3”x2.3”x1.0”(110x58x26mm)
• Weight:0.53Lbs(0.239Kg)
• Follow the standard of IEEE-568B
• Supports resolutions up to 1080p Full HD
• Supports Ethernet bandwidth: Upto 130M
• HDCO compliant
Package Included:
1Pc HDMI Extender Sender
1Pc HDMI Extender Receiver
2Pc Power supplier
1 User manual
