Newland 2D HR1250 USB Barcode Scanner
Online price
$48.00
Equipped with the a outstanding CPU, this wireless handheld scanner can effortlessly capture high-density, high-volume and distorted barcodes printed on paper or displayed on screen.
With 2200mAh battery, it will run a comfortable 12 hours of continuous use. The provided USB cable allows convenient charging.
Adopting the latest Bluetooth 5.0 technology, the NLS-HR2081-BT is able to maintain a reliable wireless connection to transmit data. The communication distances up to 50m.
The NLS-HR2081-BT, built into an IP42-sealed and drop resistant (1.5m) housing with no moving parts, fortifies itself inside and out.
SPECIFICATIONS :
| Performance | Image Sensor | 640×480 CMOS | |
| Illumination Aiming | White LED Red LED (625nm) | ||
| Symbologies | 2D | PDF417, Micro PDF 417, QR Code, Data Matrix, Micro QR Code Aztec, Data Matrix | |
| 1D | Code-11, Code-128, Code-39, GS1-128(UCC/EAN-128), AIM-128, ISBT-128, Codabar,Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-8, EAN-13, ISBN/ISSN, Interleaved 2 of 5,Febraban, Matrix 2 of 5, Industrial 25, ITF-6, ITF-14, Standard 25, China Post 25, MSI-Plessey, Plessey, GS1 Databar(RSS) | ||
| OCR | Passport OCR | ||
| Resolution | ≥3mil | ||
| Typical Depth of Field | EAN-13 QR Code Code 39 PDF 417 Data Matrix | 45mm-260mm (13mil) 30mm-170mm (15mil) 45mm-115mm (5mil) 50mm-120mm (6.67mil) 35mm-125mm (10mil) | |
| Scan Angle | Pitch | ±60° | |
| Roll | 360° | ||
| Skew | ±60° | ||
| Field of View | Horizontal 45°, Vertical 34° | ||
| Min. Symbol Contrast | 20% | ||
| Wireless | Communication Mode | Synchronous mode, automatic batch mode and manual batch mode | |
| Radio Technology | Bluetooth 5.0 | ||
| Communication Distance (direct line of sight in open air) | With Bluetooth | ≥50m | |
| Memory Capacity | ≥15000 pieces Code 128 (20 byte of each Code 128) | ||
| Battery | 2200 mAh lithium-ion battery | ||
| Expected Charge Time | 5.5 hours (with power adapter) | ||
| Expected Battery Life | 12 hours of continuous operation (scan once per 6 seconds) | ||
| Physical | Interfaces | USB | |
| Dimensions (L×W×H) | 145×101×68mm | ||
| Weight | 167g | ||
| Notification | Beep, LED indicator, vibration | ||
| Charge Voltage | 5VDC±5% | ||
| Environmental | Operating Temperature | -20°C to 60°C (-4°F to 140°F) | |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) | ||
| Charge Temperature | 0°C to 45°C (32°F to 113°F) | ||
| Humidity | 5% ~ 95% (non-condensing) | ||
| ESD | ±15 KV (air discharge); ±8 KV (direct discharge) | ||
| Drop | 1.5m | ||
| Sealing | IP42 | ||
| Certifications | KC |
