Portable 2.5" Wrist Monitor for CCTV

start of prefixes

2.5 inch portable CCTV testing monitor with wrist strap

1.2.5-inch TFT LCD monitor
2. Manual operation
3. Video System input PAL/NTSC
4. Specially used in CCTV testing and monitoring
5. Available for navigation.
6. No radiation

Parameter
Product Name: 2.5 inch portable CCTV testing monitor with wrist strap
Product Model: TYL-M025LCD
Display area: 48.0(H)*35.685(V)mm
Aspect ratio: 4: 3
Backlight life span: beyond 50000h
Resolutions: 320*240
Brightness: 350cd/m2
Contrast ratio: 200: 1
Response time: 15ms
Dot pitch: 0.1(H)*0.1525(V)mm
Colors: 16.7M
Viewing angle: (up/down /left/right): (10/30/40/40)
Video format : PAL\NTSC automatic recognition
Video signal : 1.0vp-p75ohm
Video interface: 1 Ch(BNC)video IN
Audio signal : /
Control mode: Thumb wheel control Support
Touch button: /
Infared remote control: /
Working voltage: DC 3.7V-DC 5V
Battery capacity: DC3.7V 1000mAh
Mac power consumption: 1.2W
Temperature: 0~60 deg C
Humidity: 5~95%RH
Appearance information: Weight 50g
Dimension : (L)85mm*(H)65mm*(T)22.5mm
