Single Mode SC to APC Fiber Cable Connector

start of prefixes

Field Assemble SC connectors enables fast, on-site installation for single-mode Fiber to FTTH drop cable connections without polishing. It is assembled on the cable sheath to eliminate bare fiber storage.

• Easy assembly, average assembly time ≤ 60s, one time success rate reaches 98%
• Connection can be verified easily after assembly
• No special tools required to open and close the connector
• No need for fusion splicer

Features:

• Connector Type: SC/APC
• For 900µm Fiber or Drop Fiber
• Re-assemblable (up to 3 times)
• Insertion loss:
  • Maximum ≤ 0.50 dB
  • Typical ≤ 0.30 dB
• Return loss::
  • UPC ≤ 50 dB
  • APC ≤ 55 dB
• Working temperature: -40ºC ～ 70ºC
