Tone Generator Probe Tracer Network cable tester

start of prefixes

Specifications:

• This Cable Tracker is designed to identify and trace wires or cables within a group without damaging the insulation. For telephone line, it can identify some states in the line. With this instrument install, debug, and maintain telephone line is more convenient. A Sender and Receiver is included in the Cable Tracker.
• Testing polarity of phone lines, Tracing a wire
• Finding wires buried behind drywall
• Test whether a cable is interrupted, Find interrupts in cable
• Compatible with all common tracing tone sources, Judge continuity of the cables or wires
• Track the cables or wires, and diagnose the break point.
• Receive the tone signal on the cables or wires (telephone line)
• Identify the state in the working telephone line (clear, ring, busy)
• Send a single solid tone or dual alternating tone to the object cables or wires

Receiver:

• On/Off button
• Test button
• 3.5 mm earphone jack

Sender:

• Tone/Off/Cont (Continuity) switch
• Tone/Cont (Continuity) LEDs
• Red and black test leads cable (61cm length, approximate)
• Built-in RJ-11 telephone cable (47cm length, approximate)
• Receiver Dimensions: 23 x 4 x 2.3cm (H x W x D, approximate)
• Sender Dimensions: 6.5 x 5.6 x 2.1cm (H x W x D, approximate)
• Power : 9V battery (6F22) included
