Ubiquiti UniFi Flex 5 Port Managed Gigabit PoE Network Switch

• The UniFi Switch, model USW-Flex, is a configurable Layer 2 Gigabit switch with auto-sensing 802.3at PoE.
• It offers 5 RJ45 Gigabit Ethernet ports, providing 1 PoE input and 4 PoE output links to your devices.
• The UniFi Switch Flex features a single PoE In port for power and four PoE ports that provide up to 15W PoE output to power a UniFi access point or other PoE devices.
• It has weatherproof housing and offers versatile mounting options.
• Managed and configured by the UniFi Controller or UniFi Mobile app, the UniFi Switch Flex offers basic Layer 2 switching protocols and features.
• The UniFi Controller and mobile app allow admins to configure and monitor virtually all of the switch features using a graphical user interface from anywhere.

Product Specifications
• Networking Interfaces: (5) 10/100/1000 Mbps RJ45 Ports
• Management Interfaces: Ethernet In-Band
• Power Method:
     • PoE Mode 1: 802.3af/at (Pins 1, 2+; 3, 6-)
     • PoE Mode 2: 802.3bt (Pins 1, 2+; 3, 6- and 4, 5+; 7, 8-)
     • PoE Mode 3: 50V/60W PoE Adapter3
• PoE Out: 802.3af (Pins 1, 2+; 3, 6-)
• Max. Power Consumption: 5W
• Max PoE+ Wattage Per Port: 15.4W
• Total PoE Power Budget:
     • Powered by AF mode PSE: 8W
     • Powered by AT mode PSE: 20W
     • Powered by BT mode PSE: 46W
     • Powered by PoE Adapter (Enabled in Controller): 46W
• Voltage Range:
     • 802.3af: 44 - 57V
     • 802.3at/bt: 50 - 57V
• LEDs:
     • System: Status
     • RJ45 Data Ports: PoE; Link/Speed/Activity
• ESD/EMP Protection: ± 16kV Air, ± 16kV Contact
• Operating Temperature:
     • 46W PoE Output: -40 to 55°C (-40 to 131°F)
     • 25W PoE Output: -40 to 65°C (-40 to 149°F)
• Operating Humidity: 5 to 95% Non-condensing
• Certifications: CE, FCC, IC

Product Includes
(1) Ubiquiti UniFi Switch Flex
(1) Wall Mount
(1) Pole Mount
(1) Port Cover
(2) Screw Anchors
(2) Mounting Screws
(2) Zip Ties
